Average Speed Display, Checking

(0 km/h or 0 MPH)

Note

Speed signal is used to determine this display.
^ switch ignition ON
^ select average speed display (0 km/h or 0 MPH) with function selector switch

^ drive vehicle and push RESET button for at least 2 seconds
^ instantaneous speed is indicated

If no display is indicated, speed signal is not present and/or speedometer or printed circuit board is defective
^ check speed signal, see Repair Group 90
^ replace speedometer and/or printed circuit board
