Control Module TCM Is Not Coded

P0702 - CONTROL MODULE TCM IS NOT CODED





When Monitored and Set Condition
^ When Monitored: With the ignition on.
^ Set Condition: The TCM has not been coded.

POSSIBLE CAUSES

- TRANSMISSION CONTROL MODULE NOT CODED

Diagnostic Test

1. TRANSMISSION CONTROL MODULE NOT CODED





The Transmission Control Module was not coded and must be replaced.

View repair.

Repair
Replace the Transmission Control Module.
Perform NAG1 TRANSMISSION VERIFICATION TEST. Verification Tests
