Invalid Control Module Version

P0702 - INVALID CONTROL MODULE VERSION





When Monitored and Set Condition
^ When Monitored: With the ignition on.
^ Set Condition: The TCM is not the correct one for the vehicle or has not been coded properly.

POSSIBLE CAUSES

- TRANSMISSION CONTROL MODULE

Diagnostic Test

1. VALIDATE PART NUMBER AND CODING





The Transmission Control Module was not coded or is the wrong part and must be replaced.

View repair.

Repair
Replace the Transmission Control Module.
Perform NAG1 TRANSMISSION VERIFICATION TEST. Verification Tests
