Rabs Module Connector Terminals - Manual Revision

9207ford04

Article No.
91-25B-32

12/20/91


ELECTRICAL/VACUUM TROUBLESHOOTING MANUAL - 1991 - PAGE 150-15 RABS MODULE CONNECTOR TERMINALS INCORRECTLY IDENTIFIED


LIGHT TRUCK: 1991 EXPLORER






ISSUE: The RABS Module Connector Terminals shown on Page 150-15 of the 1991 Explorer EVTM are incorrectly identified.


ACTION: Refer to the page following this TSB article for the revised information.


OTHER APPLICABLE ARTICLES: NONE
WARRANTY STATUS: INFORMATION ONLY
OASIS CODES: 290000
