Home >> Ford >> 1985 >> Escort L4-116 1.9L VIN 9 2-bbl >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Trunk / Liftgate Relay >> Liftback

Liftback

Fig. 43 Liftgate Release & Wiper/Washer Wiring Circuit. 1985 Liftback:
