Rear Wheel Alignment

REAR WHEEL ALIGNMENT

TOE-IN
Standard value: 2 ± 2 mm





NOTE: The assist arm mounting bolt (crossmember side) should be turned an equal amount on both sides when adjusting.

Inside direction of the vehicle - toe-in
Outside direction of the vehicle - toe-out
The scale has gradations of approximately 2.4 mm (14').

CAMBER
Standard value: -30' ± 30'





NOTE:
1. The rear suspension assembly must be free of worn, loose or damaged parts prior to measuring rearwheel alignment.
2. Camber is pre-set at the factory and cannot be adjusted.
3. If camber is not within the specifications, replace bent or damaged parts.
