Quick Inspection, Rear

Rear Disc Pad Inspection (On-Vehicle)
1. Jack up the front of the vehicle and support it with safety stands.
2. Remove the wheel and tires.



3. Verify the remaining thickness of the pads.

Minimum Thickness: 1.0 mm {0.039 in}
