Headlamp Switch: Service and Repair

REMOVAL PROCEDURE
1. Remove the IP cluster trim panel.
2. Remove the fuel door/trunk release switch fasteners (3).
3. Disconnect the electrical connector (1).
4. Remove the switch (2).
5. Remove the panel lights switch (4) fasteners.
6. Pull rearward on the switch in order to remove the switch.

INSTALLATION PROCEDURE
1. Install the panel lights switch (4).
2. Install the fasteners (3).
3. Connect the electrical connector (1) to the fuel door/trunk release switch (2).
4. Install the fasteners.
5. Install the IP cluster trim panel.
