Shift Interlock: Testing and Inspection

Basic Diagnostic Chart:

Diagnostic Procedure No. 1:

Diagnostic Procedure No. 2 (Shift Lock Does Not Release):

Diagnostic Procedure No. 3 (Key Interlock Does Not Operate):

Diagnostic Procedure No. 4 (Key Interlock Does Not Release):
